Feature
EHCI Controller
EHCI Hub Root Port
Hub Port 0
Hub Port 1
Hub Port 2
Hub Port 3
EHCI Debug Port
11.3.23

Diagnostic Settings Submenu

Feature
Relay Interface
Primary Port Addr. Lowbyte (Dec)
Primary Port Addr. Highbyte (Dec)
Relay Device Address (Dec)
BC Diagnostic Console Interface
Parity Bit
Stop Bits
Copyright © 2016 congatec AG
Options Description
Disabled Enable or disable the EHCI (USB 2.0) host controller.
Enabled
Disabled Enable or disable EHCI hub root port.
Enabled
Disabled Enable or disable the current USB hub port.
Enabled
Disabled Enable or disable the current USB hub port.
Enabled
Disabled Enable or disable the current USB hub port.
Enabled
Disabled Enable or disable the current USB hub port.
Enabled
Disabled Enable or disable the EHCI debug port.
Enabled
Options Description
Disabled Select post code redirection relay interface used for debugging.
I2C
SMBus
BC Diagnostic
Console
Default: 128 Select primary port address low byte as decimal.
0 - 255
0 - 255 Select primary port address high byte as decimal.
Default: 226 Select relay device address (I2C or SMBus mode only)
0 - 255
Disabled Select BC diagnostic console interface.
BC AUX Port
BC COM Port 0
BC COM Port 1
No Parity Select parity of BC diagnostic console interface.
Even Parity
Odd Parity
1 Stop Bit Select stop bits count of BC diagnostic console interface.
2 Stop Bits
