VLT Automation Drive FC 300 12-Pulse
How to Program
Instruction Manual High Power

4.2 Quick Set-up

0-01 Language
Option: Function:
Defines the language to be used in the
display. The adjustable frequency drive
can be delivered with 4 different
language packages. English and German
are included in all packages. English
cannot be erased or manipulated.
[0] English Part of Language packages 1 - 4
[1] Deutsch Part of Language packages 1 - 4
[2] Francais Part of Language package 1
[3] Dansk Part of Language package 1
[4] Spanish Part of Language package 1
[5] Italiano Part of Language package 1
Svenska Part of Language package 1
[7] Nederlands Part of Language package 1
[10] Chinese Part of Language package 2
Suomi Part of Language package 1
[22] English US Part of Language package 4
Greek Part of Language package 4
Bras.port Part of Language package 4
Slovenian Part of Language package 3
Korean Part of Language package 2
Japanese Part of Language package 2
Turkish Part of Language package 4
Trad.Chinese Part of Language package 2
Bulgarian Part of Language package 3
Srpski Part of Language package 3
Romanian Part of Language package 3
Magyar Part of Language package 3
Czech Part of Language package 3
Polski Part of Language package 4
Russian Part of Language package 3
Thai Part of Language package 2
Bahasa Indonesia Part of Language package 2
[52] Hrvatski
MG34Q222 - VLT ® is a registered Danfoss trademark
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
1-20 Motor Power [kW]
Range: Function:
Application [Application Enter the nominal motor power in
dependent dependant] kW according to the motor
*
nameplate data. The default value
corresponds to the nominal rated
output of the unit.
This parameter cannot be
adjusted while the motor is
running. This parameter is visible
in LCP if 0-03 Regional Settings is
International [0].
NOTE!
Four sizes down, one size up
from nominal unit rating.
1-22 Motor Voltage
Range: Function:
Size [ 10. - Enter the nominal motor voltage
related 1000. V] according to the motor nameplate
*
data. The default value corresponds to
the nominal rated output of the unit.
This parameter cannot be adjusted
while the motor is running.
1-23 Motor Frequency
Range: Function:
Application [20 - Min - Max motor frequency: 20–1,000 Hz.
dependent * 1000 Select the motor frequency value from
Hz] the motor nameplate data. If a value
different from 50 Hz or 60 Hz is selected,
it is necessary to adapt the load
independent settings in 1-50 Motor
Magnetization at Zero Speed to 1-53 Model
Shift Frequency. For 87 Hz operation with
230/400 V motors, set the nameplate
data for 230 V/50 Hz. Adapt 4-13 Motor
Speed High Limit [RPM] and
3-03 Maximum Reference to the 87 Hz
application.
1-24 Motor Current
Range: Function:
Size [ 0.10 - Enter the nominal motor current
related 10000.00 A] value from the motor nameplate
*
data. This data is used for
calculating motor torque, motor
thermal protection, etc.
4-3
4 4
