2 Safety Instructions and General Warning

CAUTION
The adjustable frequency drive DC link capacitors remain
charged after power has been disconnected. To avoid the
electrical shock hazard, disconnect the adjustable
frequency drive from line power before carrying out
maintenance. Before servicing the adjustable frequency
drive, wait the minimum amount of time indicated below:
380–500 V 350–1,075 hp 40 minutes
[250–800 kW]
525–690 V 500–1,900 hp 30 minutes
[355–1,400 kW]
Table 2.1
VLT AutomationDrive
Instruction Manual
Software version: 6.5x
This Instruction Manual can be used for all VLT AutomationDrive
adjustable frequency drives with software version 6.5x.
The software version number can be seen from 15-43 Software
Version.
Table 2.2

2.1.1 High Voltage

WARNING
The voltage of the adjustable frequency drive is dangerous
whenever the Adjustable frequency drive is connected to
line power. Incorrect installation or operation of the motor
or adjustable frequency drive may cause damage to the
equipment, serious personal injury or death. The
instructions in this manual must therefore be observed, in
addition to applicable local and national rules and safety
regulations.
WARNING
Installation at high altitudes
380–500 V: At altitudes above 10,000 feet [3 km], please
contact Danfoss regarding PELV.
525–690 V: At altitudes above 6,600 feet [2 km], please
contact Danfoss regarding PELV.
