VLT Automation Drive FC 300 12-Pulse
How to Program
Instruction Manual High Power
Par. Parameter description Default value
No.
#
35-27 Term. X48/7 High Temp. Limit ExpressionLimit
35-3* Temp. Input X48/10
35-34 Term. X48/10 Filter Time Constant 0.001 s
35-35 Term. X48/10 Temp. Monitor [0] Disabled
35-36 Term. X48/10 Low Temp. Limit ExpressionLimit
35-37 Term. X48/10 High Temp. Limit ExpressionLimit
35-4* Analog Input X48/2
35-42 Term. X48/2 Low Current 4.00 mA
35-43 Term. X48/2 High Current 20.00 mA
35-44 Term. X48/2 Low Ref./Feedb. Value 0.000 N/A
35-45 Term. X48/2 High Ref./Feedb. Value 100.000 N/A
35-46 Term. X48/2 Filter Time Constant 0.001 s
Table 4.27
