VLT
How to Program
Instruction Manual High Power
4.1.2 Initial Commissioning
The easiest way of carrying out the initial commissioning is by using the [Quick Menu] key and following the quick set-up
procedure using LCP 102 (read table from left to right). The example applies to open-loop applications.
Press
4 4
Quick
Menu
0-01 Language OK
1-20 Motor Power [kW] OK
1-22 Motor Voltage OK
1-23 Motor Frequency OK
1-24 Motor Current OK
1-25 Motor Nominal Speed OK
5-12 Terminal 27 Digital Input OK
1-29 Automatic Motor Adaptation
OK
(AMA)
3-02 Minimum Reference OK
3-03 Maximum Reference OK
3-41 Ramp 1 Ramp-up Time OK
3-42 Ramp 1 Ramp-down Time OK
3-13 Reference Site OK
Table 4.1
4-2 MG34Q222 - VLT
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
®
Automation Drive FC 300 12-Pulse
Q2 Quick Menu OK
Set language
Set motor nameplate power
Set nameplate voltage
Set nameplate frequency
Set nameplate current
Set nameplate speed in RPM
If terminal default is Coast
inverse, it is possible to change
this setting to No function. No
connection to terminal 27 is
then needed for running AMA
Set desired AMA function.
Enabling complete AMA is
recommended
Set the minimum speed of the
motor shaft
Set the maximum speed of the
motor shaft
Set the ramping-up time with
reference to synchronous
motor speed, ns.
Set the ramping-down time
with reference to synchronous
motor speed, ns.
Set the site from where the
reference must work
