Closed-Loop Set-Up Quick Guide - Danfoss VLT Compressor Drive CDS 803 Design Manual

Product Overview

2.6.6 Closed-loop Set-up Quick Guide

Illustration 2.6 Closed-loop Set-up Quick Guide
MG18N202
Design Guide
0-01 Language
1
[0] English
0-06 Grid Type
2
Size related
0-60 Main Menu Password
3
[0]
1-00 Con guration Mode
4
[0]
Size related
1-13 Compressor Selection
5
[1]
Closed loop
3-02 Minimum Reference
6
0 Hz
3-03 Maximum Reference
7
Hz
200
3-10 Preset Reference
8
0%
3-15 Reference 1 Source
9
[1] Analog in 53
3-41 Ramp 1 Ramp Up Time
10
30.00
s
3-42 Ramp 1 Ramp Down Time
11
30.00 s
5
5-12 Terminal 27 Digital Input
12
[6] Stop inverse
5-40 Function Relay 1
13
Alarm
5-40 Function Relay 2
14
Drive running
6-10 Terminal 53 Low Voltage
15
0.07 V
6-11 Terminal 53 High Voltage
16
10 V
6-14 Terminal 53 Low Ref./Feedb.
17
30.000
Hz
6-15 Terminal 53 High Ref./Feedb.
18
200.000 Hz
6-22 Terminal 54 Low Current
19
4.00
mA
6-23 Terminal 54 High Current
20
20.00
mA
6-24 Terminal 54 Low Ref./Feedb.
21
0.000
0
22 6-25 Terminal 54 High Ref./Feedb.
4999.000
20-00 Feedback 1 Source
23
[2]
0.00
Analog input 54
20-04 Feedback 2 Conversion
24
[0]
Linear
8-01 Control Site
25
[0]
Digital and ctrl.word
8-30 Protocol
26
[0] FC
27
8-31 Address
1
