VLT Automation Drive FC 300 12-Pulse
How to Program
Instruction Manual High Power
Par. Parameter description Default value
No.
#
17-6* Monitoring and App.
17-60 Feedback Direction [0] Clockwise
17-61 Feedback Signal Monitoring [1] Warning
Table 4.21
4.3.19 18-** Data Readouts 2
Par. Parameter description Default value
No.
#
18-3* Analog Readouts
18-36 Analog Input X48/2 [mA] 0.000 N/A
18-37 Temp. Input X48/4 0 N/A
18-38 Temp. Input X48/7 0 N/A
18-39 Temp. Input X48/10 0 N/A
18-6* Inputs & Outputs 2
18-60 Digital Input 2 0 N/A
18-9* PID Readouts
18-90 Process PID Error 0.0 %
18-91 Process PID Output 0.0 %
18-92 Process PID Clamped Output 0.0 %
18-93 Process PID Gain Scaled Output 0.0 %
Table 4.22
4.3.20 30-** Special Features
Par. Parameter description Default value
No.
#
30-0* Wobbler
30-00 Wobble Mode [0] Abs. Freq., Abs. Time
30-01 Wobble Delta Frequency [Hz] 5.0 Hz
30-02 Wobble Delta Frequency [%] 25 %
30-03 Wobble Delta Freq. Scaling Resource [0] No function
30-04 Wobble Jump Frequency [Hz] 0.0 Hz
30-05 Wobble Jump Frequency [%] 0 %
30-06 Wobble Jump Time ExpressionLimit
30-07 Wobble Sequence Time 10.0 s
30-08 Wobble Up/Down Time 5.0 s
30-09 Wobble Random Function [0] Off
30-10 Wobble Ratio 1.0 N/A
30-11 Wobble Random Ratio Max. 10.0 N/A
30-12 Wobble Random Ratio Min. 0.1 N/A
30-19 Wobble Delta Freq. Scaled 0.0 Hz
30-2* Adv. Start Adjust
30-20 High Starting Torque Time [s] 0.00 s
30-21 High Starting Torque Current [%] 100.0 %
