VLT
How to Program
Instruction Manual High Power
Par. Parameter description
No.
#
6-44 Term. X30/12 Low Ref./Feedb. Value
6-45 Term. X30/12 High Ref./Feedb. Value
6-46 Term. X30/12 Filter Time Constant
6-5* Analog Output 1
4 4
6-50 Terminal 42 Output
6-51 Terminal 42 Output Min Scale
6-52 Terminal 42 Output Max Scale
6-53 Terminal 42 Output Bus Control
6-54 Terminal 42 Output Timeout Preset
6-55 Terminal 42 Output Filter
6-6* Analog Output 2
6-60 Terminal X30/8 Output
6-61 Terminal X30/8 Min. Scale
6-62 Terminal X30/8 Max. Scale
6-63 Terminal X30/8 Bus Control
6-64 Terminal X30/8 Output Timeout Preset
6-7* Analog Output 3
6-70 Terminal X45/1 Output
6-71 Terminal X45/1 Min. Scale
6-72 Terminal X45/1 Max. Scale
6-73 Terminal X45/1 Bus Control
6-74 Terminal X45/1 Output Timeout Preset
6-8* Analog Output 4
6-80 Terminal X45/3 Output
6-81 Terminal X45/3 Min. Scale
6-82 Terminal X45/3 Max. Scale
6-83 Terminal X45/3 Bus Control
6-84 Terminal X45/3 Output Timeout Preset
Table 4.11
4.3.9 7-** Controllers
Par. Parameter description
No.
#
7-0* Speed PID Ctrl.
7-00 Speed PID Feedback Source
7-02 Speed PID Proportional Gain
7-03 Speed PID Integral Time
7-04 Speed PID Differentiation Time
7-05 Speed PID Diff. Gain Limit
7-06 Speed PID Lowpass Filter Time
7-07 Speed PID Feedback Gear Ratio
7-08 Speed PID Feed Forward Factor
7-09 Speed PID Error Correction w/ Ramp
7-1* Torque PI Ctrl.
7-12 Torque PI Proportional Gain
4-16 MG34Q222 - VLT
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
®
Automation Drive FC 300 12-Pulse
Default value 4 set-up FC 302 Change
only during
operation
0 ReferenceFeedbackUnit All set-ups TRUE
ExpressionLimit All set-ups TRUE
0.001 s All set-ups TRUE
null All set-ups TRUE
0.00 % All set-ups TRUE
100.00 % All set-ups TRUE
0.00 % All set-ups TRUE
0.00 % 1 set-up TRUE
[0] Off 1 set-up TRUE
null All set-ups TRUE
0.00 % All set-ups TRUE
100.00 % All set-ups TRUE
0.00 % All set-ups TRUE
0.00 % 1 set-up TRUE
null All set-ups TRUE
0.00 % All set-ups TRUE
100.00 % All set-ups TRUE
0.00 % All set-ups TRUE
0.00 % 1 set-up TRUE
null All set-ups TRUE
0.00 % All set-ups TRUE
100.00 % All set-ups TRUE
0.00 % All set-ups TRUE
0.00 % 1 set-up TRUE
Default value 4 set-up FC 302 Change
only during
operation
null All set-ups FALSE
ExpressionLimit All set-ups TRUE
ExpressionLimit All set-ups TRUE
ExpressionLimit All set-ups TRUE
5.0 N/A All set-ups TRUE
ExpressionLimit All set-ups TRUE
1.0000 N/A All set-ups FALSE
0 % All set-ups FALSE
300 RPM All set-ups TRUE
100 % All set-ups TRUE
® is a registered Danfoss trademark
Conver- Type
sion
index
-3 Int32
-3 Int32
-3 Uint16
- Uint8
-2 Int16
-2 Int16
-2 N2
-2 Uint16
- Uint8
- Uint8
-2 Int16
-2 Int16
-2 N2
-2 Uint16
- Uint8
-2 Int16
-2 Int16
-2 N2
-2 Uint16
- Uint8
-2 Int16
-2 Int16
-2 N2
-2 Uint16
Conver- Type
sion
index
- Uint8
-3 Uint16
-4 Uint32
-4 Uint16
-1 Uint16
-4 Uint16
-4 Uint32
0 Uint16
67 Uint32
0 Uint16
