VLT Automation Drive FC 300 12-Pulse
How to Install
Instruction Manual High Power
1
4
CFD30J3
2
5
R/L1 91 S/L2 92 T/L3 93
6
3
R/L1 91 S/L2 92 T/L3 93
Figure 3.30 Options Cabinet, frame size F9
1) Pilz Relay Terminal
2) RCD or IRM Terminal
3) Line power/6-phase
R1 S1 T1 R2 S2 T2
91-1 92-1 93-1 91-2 92-2 93-2
L1-1 L2-1 L3-1 L1-2 L2-2 L3-2
Table 3.17
MG34Q222 - VLT ® is a registered Danfoss trademark
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
4) Safety Relay Coil Fuse with Pilz Relay
See fuse tables for part numbers
5) Electrical Fuses, (6 pieces)
See fuse tables for part numbers
6) 2 x 3-phase manual disconnect
3-29
3 3
