VLT Automation Drive FC 300 12-Pulse
How to Program
Instruction Manual High Power
Par. Parameter description Default value
No.
#
5-7* 24V Encoder Input
5-70 Term 32/33 Pulses per Revolution 1024 N/A
5-71 Term 32/33 Encoder Direction [0] Clockwise
5-8* I/O Options
5-80 AHF Cap Reconnect Delay 25 s
5-9* Bus Controlled
5-90 Digital & Relay Bus Control 0 N/A
5-93 Pulse Out #27 Bus Control 0.00 %
5-94 Pulse Out #27 Timeout Preset 0.00 %
5-95 Pulse Out #29 Bus Control 0.00 %
5-96 Pulse Out #29 Timeout Preset 0.00 %
5-97 Pulse Out #X30/6 Bus Control 0.00 %
5-98 Pulse Out #X30/6 Timeout Preset 0.00 %
Table 4.10
4.3.8 6-** Analog In/Out
Par. Parameter description Default value
No.
#
6-0* Analog I/O Mode
6-00 Live Zero Timeout Time 10 s
6-01 Live Zero Timeout Function [0] Off
6-1* Analog Input 1
6-10 Terminal 53 Low Voltage 0.07 V
6-11 Terminal 53 High Voltage 10.00 V
6-12 Terminal 53 Low Current 0.14 mA
6-13 Terminal 53 High Current 20.00 mA
6-14 Terminal 53 Low Ref./Feedb. Value 0 ReferenceFeedbackUnit
6-15 Terminal 53 High Ref./Feedb. Value ExpressionLimit
6-16 Terminal 53 Filter Time Constant 0.001 s
6-2* Analog Input 2
6-20 Terminal 54 Low Voltage 0.07 V
6-21 Terminal 54 High Voltage 10.00 V
6-22 Terminal 54 Low Current 0.14 mA
6-23 Terminal 54 High Current 20.00 mA
6-24 Terminal 54 Low Ref./Feedb. Value 0 ReferenceFeedbackUnit
6-25 Terminal 54 High Ref./Feedb. Value ExpressionLimit
6-26 Terminal 54 Filter Time Constant 0.001 s
6-3* Analog Input 53
6-30 Terminal X30/11 Low Voltage 0.07 V
6-31 Terminal X30/11 High Voltage 10.00 V
6-34 Term. X30/11 Low Ref./Feedb. Value 0 ReferenceFeedbackUnit
6-35 Term. X30/11 High Ref./Feedb. Value ExpressionLimit
6-36 Term. X30/11 Filter Time Constant 0.001 s
6-4* Analog Input 4
6-40 Terminal X30/12 Low Voltage 0.07 V
6-41 Terminal X30/12 High Voltage 10.00 V
MG34Q222 - VLT ® is a registered Danfoss trademark
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
4 set-up FC 302 Change Conver- Type
only during sion
operation index
All set-ups FALSE 0 Uint16
All set-ups FALSE - Uint8
4
2 set-ups x TRUE 0 Uint16
All set-ups TRUE 0 Uint32
All set-ups TRUE -2 N2
1 set-up TRUE -2 Uint16
All set-ups x TRUE -2 N2
1 set-up x TRUE -2 Uint16
All set-ups TRUE -2 N2
1 set-up TRUE -2 Uint16
4 set-up FC 302 Change Conver- Type
only during sion
operation index
All set-ups TRUE 0 Uint8
All set-ups TRUE - Uint8
All set-ups TRUE -2 Int16
All set-ups TRUE -2 Int16
All set-ups TRUE -5 Int16
All set-ups TRUE -5 Int16
All set-ups TRUE -3 Int32
All set-ups TRUE -3 Int32
All set-ups TRUE -3 Uint16
All set-ups TRUE -2 Int16
All set-ups TRUE -2 Int16
All set-ups TRUE -5 Int16
All set-ups TRUE -5 Int16
All set-ups TRUE -3 Int32
All set-ups TRUE -3 Int32
All set-ups TRUE -3 Uint16
All set-ups TRUE -2 Int16
All set-ups TRUE -2 Int16
All set-ups TRUE -3 Int32
All set-ups TRUE -3 Int32
All set-ups TRUE -3 Uint16
All set-ups TRUE -2 Int16
All set-ups TRUE -2 Int16
4-15
4
