VLT
How to Program
Instruction Manual High Power
4.3.2 0-** Operation/Display
Par. Parameter description
No.
#
0-0* Basic Settings
0-01 Language
4 4
0-02 Motor Speed Unit
0-03 Regional Settings
0-04 Operating State at Power-up (Hand)
0-09 Performance Monitor
0-1* Set-up Operations
0-10 Active Set-up
0-11 Edit Set-up
0-12 This Set-up Linked to
0-13 Readout: Linked Set-ups
0-14 Readout: Edit Set-ups / Channel
0-15 Readout: actual setup
0-2* LCP Display
0-20 Display Line 1.1 Small
0-21 Display Line 1.2 Small
0-22 Display Line 1.3 Small
0-23 Display Line 2 Large
0-24 Display Line 3 Large
0-25 My Personal Menu
0-3* LCP Cust. Readout
0-30 Unit for User-defined Readout
0-31 Min Value of User-defined Readout
0-32 Max Value of User-defined Readout
0-37 Display Text 1
0-38 Display Text 2
0-39 Display Text 3
0-4* LCP Keypad
0-40 [Hand on] Key on LCP
0-41 [Off] Key on LCP
0-42 [Auto on] Key on LCP
0-43 [Reset] Key on LCP
0-44 [Off/Reset] Key on LCP
0-45 [Drive Bypass] Key on LCP
0-5* Copy/Save
0-50 LCP Copy
0-51 Set-up Copy
0-6* Password
0-60 Main Menu Password
0-61 Access to Main Menu w/o Password
0-65 Quick Menu Password
0-66 Access to Quick Menu w/o Password
0-67 Bus Password Access
Table 4.5
4-8 MG34Q222 - VLT
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
®
Automation Drive FC 300 12-Pulse
Default value 4 set-up FC 302 Change
only during
operation
[0] English 1 set-up TRUE
[0] RPM 2 set-ups FALSE
[0] International 2 set-ups FALSE
[1] Forced stop, ref=old All set-ups TRUE
0.0 % All set-ups TRUE
[1] Set-up 1 1 set-up TRUE
[1] Set-up 1 All set-ups TRUE
[0] Not linked All set-ups FALSE
0 N/A All set-ups FALSE
0 N/A All set-ups TRUE
0 N/A All set-ups FALSE
1617 All set-ups TRUE
1614 All set-ups TRUE
1610 All set-ups TRUE
1613 All set-ups TRUE
1602 All set-ups TRUE
ExpressionLimit 1 set-up TRUE
[0] None All set-ups TRUE
0.00 CustomReadoutUnit All set-ups TRUE
100.00 CustomRea-
doutUnit All set-ups TRUE
0 N/A 1 set-up TRUE
0 N/A 1 set-up TRUE
0 N/A 1 set-up TRUE
null All set-ups TRUE
null All set-ups TRUE
null All set-ups TRUE
null All set-ups TRUE
null All set-ups TRUE
null All set-ups TRUE
[0] No copy All set-ups FALSE
[0] No copy All set-ups FALSE
100 N/A 1 set-up TRUE
[0] Full access 1 set-up TRUE
200 N/A 1 set-up TRUE
[0] Full access 1 set-up TRUE
0 N/A All set-ups TRUE
® is a registered Danfoss trademark
Conver- Type
sion
index
- Uint8
- Uint8
- Uint8
- Uint8
-1 Uint16
- Uint8
- Uint8
- Uint8
0 Uint16
0 Int32
0 Uint8
- Uint16
- Uint16
- Uint16
- Uint16
- Uint16
0 Uint16
- Uint8
-2 Int32
-2 Int32
VisStr[
0 25]
VisStr[
0 25]
VisStr[
0 25]
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Int16
- Uint8
0 Int16
- Uint8
0 Uint16
