VLT Automation Drive FC 300 12-Pulse
How to Program
Instruction Manual High Power
Par. Parameter description Default value
No.
#
16-05 Main Actual Value [%] 0.00 %
16-09 Custom Readout 0.00 CustomReadoutUnit
16-1* Motor Status
16-10 Power [kW] 0.00 kW
16-11 Power [hp] 0.00 hp
16-12 Motor voltage 0.0 V
16-13 Frequency 0.0 Hz
16-14 Motor Current 0.00 A
16-15 Frequency [%] 0.00 %
16-16 Torque [Nm] 0.0 Nm
16-17 Speed [RPM] 0 RPM
16-18 Motor Thermal 0 %
16-19 KTY sensor temperature 0 °C
16-20 Motor Angle 0 N/A
16-21 Torque [%] High Res. 0.0 %
16-22 Torque [%] 0 %
16-25 Torque [Nm] High 0.0 Nm
16-3* Drive Status
16-30 DC Link Voltage 0 V
16-32 Brake Energy /s 0.000 kW
16-33 Brake Energy /2 min 0.000 kW
16-34 Heatsink Temp. 0 °C
16-35 Inverter Thermal 0 %
16-36 Inv. Nom. Current ExpressionLimit
16-37 Inv. Max. Current ExpressionLimit
16-38 SL Controller State 0 N/A
16-39 Control Card Temp. 0 °C
16-40 Logging Buffer Full [0] No
16-41 LCP Bottom Statusline 0 N/A
16-49 Current Fault Source 0 N/A
16-5* Ref. & Feedb.
16-50 External Reference 0.0 N/A
16-51 Pulse Reference 0.0 N/A
0.000 ReferenceFeed-
16-52 Feedback [Unit] backUnit
16-53 Digi Pot Reference 0.00 N/A
16-57 Feedback [RPM] 0 RPM
16-6* Inputs & Outputs
16-60 Digital Input 0 N/A
16-61 Terminal 53 Switch Setting [0] Current
16-62 Analog Input 53 0.000 N/A
16-63 Terminal 54 Switch Setting [0] Current
16-64 Analog Input 54 0.000 N/A
16-65 Analog Output 42 [mA] 0.000 N/A
16-66 Digital Output [bin] 0 N/A
16-67 Freq. Input #29 [Hz] 0 N/A
16-68 Freq. Input #33 [Hz] 0 N/A
MG34Q222 - VLT ® is a registered Danfoss trademark
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
4 set-up FC 302 Change Conver- Type
only during sion
operation index
All set-ups FALSE -2 N2
All set-ups FALSE -2 Int32
All set-ups FALSE 1 Int32
4
All set-ups FALSE -2 Int32
All set-ups FALSE -1 Uint16
All set-ups FALSE -1 Uint16
All set-ups FALSE -2 Int32
All set-ups FALSE -2 N2
All set-ups FALSE -1 Int16
All set-ups FALSE 67 Int32
All set-ups FALSE 0 Uint8
All set-ups FALSE 100 Int16
All set-ups TRUE 0 Uint16
All set-ups FALSE -1 Int16
All set-ups FALSE 0 Int16
All set-ups FALSE -1 Int32
All set-ups FALSE 0 Uint16
All set-ups FALSE 0 Uint32
All set-ups FALSE 0 Uint32
All set-ups FALSE 100 Uint8
All set-ups FALSE 0 Uint8
All set-ups FALSE -2 Uint32
All set-ups FALSE -2 Uint32
All set-ups FALSE 0 Uint8
All set-ups FALSE 100 Uint8
All set-ups TRUE - Uint8
VisStr[
All set-ups TRUE 0 50]
All set-ups x TRUE 0 Uint8
All set-ups FALSE -1 Int16
All set-ups FALSE -1 Int16
All set-ups FALSE -3 Int32
All set-ups FALSE -2 Int16
All set-ups FALSE 67 Int32
All set-ups FALSE 0 Uint16
All set-ups FALSE - Uint8
All set-ups FALSE -3 Int32
All set-ups FALSE - Uint8
All set-ups FALSE -3 Int32
All set-ups FALSE -3 Int16
All set-ups FALSE 0 Int16
All set-ups x FALSE 0 Int32
All set-ups FALSE 0 Int32
4-25
4
