Danfoss vlt fc 300 Instruction Manual page 75

VLT
How to Program
Instruction Manual High Power
Par. Parameter description
No.
#
8-10 Control Word Profile
8-13 Configurable Status Word STW
8-14 Configurable Control Word CTW
8-3* FC Port Settings
4 4
8-30 Protocol
8-31 Address
8-32 FC Port Baud Rate
8-33 Parity / Stop Bits
8-34 Estimated cycle time
8-35 Minimum Response Delay
8-36 Max Response Delay
8-37 Max Inter-Char Delay
8-4* FC MC protocol set
8-40 Telegram selection
8-41 Parameters for signals
8-42 PCD write configuration
8-43 PCD read configuration
8-5* Digital/Bus
8-50 Coasting Select
8-51 Quick Stop Select
8-52 DC Brake Select
8-53 Start Select
8-54 Reverse Select
8-55 Set-up Select
8-56 Preset Reference Select
8-57 Profidrive OFF2 Select
8-58 Profidrive OFF3 Select
8-8* AFD Port Diagnostics
8-80 Bus Message Count
8-81 Bus Error Count
8-82 Slave Messages Rcvd
8-83 Slave Error Count
8-9* Bus Jog
8-90 Bus Jog 1 Speed
8-91 Bus Jog 2 Speed
Table 4.13
4.3.11 9-** Profibus
Par. Parameter description
No.
#
9-00 Setpoint
9-07 Actual Value
9-15 PCD Write Configuration
9-16 PCD Read Configuration
9-18 Node Address
4-18 MG34Q222 - VLT
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
®
Automation Drive FC 300 12-Pulse
Default value 4 set-up FC 302 Change
only during
operation
[0] FC profile All set-ups TRUE
null All set-ups TRUE
[1] Profile default All set-ups TRUE
[0] FC 1 set-up TRUE
1 N/A 1 set-up TRUE
null 1 set-up TRUE
[0] Ev. Par. 1 Stop Bit 1 set-up TRUE
0 ms 2 set-ups TRUE
10 ms All set-ups TRUE
ExpressionLimit 1 set-up TRUE
ExpressionLimit 1 set-up TRUE
[1] Standard telegram 1 2 set-ups TRUE
0 All set-ups FALSE
ExpressionLimit All set-ups TRUE
ExpressionLimit All set-ups TRUE
[3] Logic OR All set-ups TRUE
[3] Logic OR All set-ups TRUE
[3] Logic OR All set-ups TRUE
[3] Logic OR All set-ups TRUE
[3] Logic OR All set-ups TRUE
[3] Logic OR All set-ups TRUE
[3] Logic OR All set-ups TRUE
[3] Logic OR All set-ups TRUE
[3] Logic OR All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
100 RPM All set-ups TRUE
ExpressionLimit All set-ups TRUE
Default value 4 set-up FC 302 Change
only during
operation
0 N/A All set-ups TRUE
0 N/A All set-ups FALSE
ExpressionLimit 1 set-up TRUE
ExpressionLimit 2 set-ups TRUE
126 N/A 1 set-up TRUE
® is a registered Danfoss trademark
Conver- Type
sion
index
- Uint8
- Uint8
- Uint8
- Uint8
0 Uint8
- Uint8
- Uint8
-3 Uint32
-3 Uint16
-3 Uint16
-5 Uint16
- Uint8
- Uint16
0 Uint16
0 Uint16
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Uint32
0 Uint32
0 Uint32
0 Uint32
67 Uint16
67 Uint16
Conver- Type
sion
index
0 Uint16
0 Uint16
- Uint16
- Uint16
0 Uint8
