Danfoss vlt fc 300 Instruction Manual page 68

®
VLT Automation Drive FC 300 12-Pulse
How to Program
Instruction Manual High Power
Par. Parameter description Default value
No.
#
2-13 Brake Power Monitoring [0] Off
2-15 Brake Check [0] Off
2-16 AC brake Max. Current 100.0 %
2-17 Over-voltage Control [0] Disabled
2-18 Brake Check Condition [0] At Power-up
2-19 Over-voltage Gain 100 %
2-2* Mechanical Brake
2-20 Release Brake Current ImaxVLT (P1637)
2-21 Activate Brake Speed [RPM] ExpressionLimit
2-22 Activate Brake Speed [Hz] ExpressionLimit
2-23 Activate Brake Delay 0.0 s
2-24 Stop Delay 0.0 s
2-25 Brake Release Time 0.20 s
2-26 Torque Ref 0.00 %
2-27 Torque Ramp Time 0.2 s
2-28 Gain Boost Factor 1.00 N/A
Table 4.7
4.3.5 3-** Reference / Ramps
Par. Parameter description Default value
No.
#
3-0* Reference Limits
3-00 Reference Range null
3-01 Reference/Feedback Unit null
3-02 Minimum Reference ExpressionLimit
3-03 Maximum Reference ExpressionLimit
3-04 Reference Function [0] Sum
3-1* References
3-10 Preset Reference 0.00 %
3-11 Jog Speed [Hz] ExpressionLimit
3-12 Catch up/slow-down Value 0.00 %
3-13 Reference Site [0] Linked to Hand / Auto
3-14 Preset Relative Reference 0.00 %
3-15 Reference Resource 1 null
3-16 Reference Resource 2 null
3-17 Reference Resource 3 null
3-18 Relative Scaling Reference Resource [0] No function
3-19 Jog Speed [RPM] ExpressionLimit
3-4* Ramp 1
3-40 Ramp 1 Type [0] Linear
3-41 Ramp 1 Ramp-up Time ExpressionLimit
3-42 Ramp 1 Ramp-down Time ExpressionLimit
3-45 Ramp 1 S-ramp Ratio at Accel. Start 50 %
3-46 Ramp 1 S-ramp Ratio at Accel. End 50 %
3-47 Ramp 1 S-ramp Ratio at Decel. Start 50 %
3-48 Ramp 1 S-ramp Ratio at Decel. End 50 %
MG34Q222 - VLT ® is a registered Danfoss trademark
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
4 set-up FC 302 Change Conver- Type
only during sion
operation index
All set-ups TRUE - Uint8
All set-ups TRUE - Uint8
All set-ups TRUE -1 Uint32
All set-ups TRUE - Uint8
4
All set-ups TRUE - Uint8
All set-ups TRUE 0 Uint16
All set-ups TRUE -2 Uint32
All set-ups TRUE 67 Uint16
All set-ups TRUE -1 Uint16
All set-ups TRUE -1 Uint8
All set-ups TRUE -1 Uint8
All set-ups TRUE -2 Uint16
All set-ups TRUE -2 Int16
All set-ups TRUE -1 Uint8
All set-ups TRUE -2 Uint16
4 set-up FC 302 Change Conver- Type
only during sion
operation index
All set-ups TRUE - Uint8
All set-ups TRUE - Uint8
All set-ups TRUE -3 Int32
All set-ups TRUE -3 Int32
All set-ups TRUE - Uint8
All set-ups TRUE -2 Int16
All set-ups TRUE -1 Uint16
All set-ups TRUE -2 Int16
All set-ups TRUE - Uint8
All set-ups TRUE -2 Int32
All set-ups TRUE - Uint8
All set-ups TRUE - Uint8
All set-ups TRUE - Uint8
All set-ups TRUE - Uint8
All set-ups TRUE 67 Uint16
All set-ups TRUE - Uint8
All set-ups TRUE -2 Uint32
All set-ups TRUE -2 Uint32
All set-ups TRUE 0 Uint8
All set-ups TRUE 0 Uint8
All set-ups TRUE 0 Uint8
All set-ups TRUE 0 Uint8
4-11
4
