VLT Automation Drive FC 300 12-Pulse
How to Program
Instruction Manual High Power
Par. Parameter description Default value
No.
#
9-22 Telegram Selection [100] None
9-23 Parameters for Signals
9-27 Parameter Edit [1] Enabled
9-28 Process Control [1] Enable cyclic master
9-44 Fault Message Counter 0 N/A
9-45 Fault Code 0 N/A
9-47 Fault Number 0 N/A
9-52 Fault Situation Counter 0 N/A
9-53 Profibus Warning Word 0 N/A
9-63 Actual Baud Rate [255] No baud rate found
9-64 Device Identification 0 N/A
9-65 Profile Number 0 N/A
9-67 Control Word 1 0 N/A
9-68 Status Word 1 0 N/A
9-71 Profibus Save Data Values [0] Off
9-72 ProfibusDriveReset [0] No action
9-75 DO Identification 0 N/A
9-80 Defined Parameters (1) 0 N/A
9-81 Defined Parameters (2) 0 N/A
9-82 Defined Parameters (3) 0 N/A
9-83 Defined Parameters (4) 0 N/A
9-84 Defined Parameters (5) 0 N/A
9-90 Changed Parameters (1) 0 N/A
9-91 Changed Parameters (2) 0 N/A
9-92 Changed Parameters (3) 0 N/A
9-93 Changed Parameters (4) 0 N/A
9-94 Changed parameters (5) 0 N/A
9-99 Profibus Revision Counter 0 N/A
Table 4.14
4.3.12 10-** CAN Ser. Com. Bus
Par. Parameter description Default value
No.
#
10-0* Common Settings
10-00 CAN Protocol null
10-01 Baud Rate Select null
10-02 MAC ID ExpressionLimit
10-05 Readout Transmit Error Counter 0 N/A
10-06 Readout Receive Error Counter 0 N/A
10-07 Readout Bus Off Counter 0 N/A
10-1* DeviceNet
10-10 Process Data Type Selection null
10-11 Process Data Config Write ExpressionLimit
10-12 Process Data Config Read ExpressionLimit
10-13 Warning Parameter 0 N/A
MG34Q222 - VLT ® is a registered Danfoss trademark
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
4 set-up FC 302 Change Conver-
only during sion
operation index
1 set-up TRUE -
0 All set-ups TRUE -
2 set-ups FALSE -
2 set-ups FALSE -
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE -
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE -
1 set-up FALSE -
All set-ups TRUE 0
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups TRUE 0
4 set-up FC 302 Change Conver-
only during sion
operation index
2 set-ups FALSE -
2 set-ups TRUE -
2 set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE 0
Type
Uint8
Uint16
Uint16
Uint8
4 4
Uint16
Uint16
Uint16
Uint16
V2
Uint8
Uint16
OctStr[
2]
V2
V2
Uint8
Uint8
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Type
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint16
Uint16
Uint16
4-19
