Warnings and Alarms
Instruction Manual High Power
1 = left most inverter module.
2 = middle inverter module in F12 or F13 frame
sizes.
2 = right inverter module in F10 or F11 frame
sizes.
2 = second drive from the left inverter module in
F14 frame size.
3 = right inverter module in F12 or F13 frame
sizes.
3 = third drive from the left inverter module in
F14 frame size.
6 6
4 = far right inverter module in F14 frame size.
5 = rectifier module.
6 = right rectifier module in F14 frame size.
ALARM 246, Power card supply
This alarm is only for F Frame adjustable frequency drive. It
is equivalent to Alarm 46. The report value in the alarm
log indicates which power module generated the alarm.
1 = left most inverter module.
2 = middle inverter module in F12 or F13 frame
sizes.
2 = right inverter module in F10 or F11 frame
sizes.
2 = second drive from the left inverter module in
F14 frame size.
3 = right inverter module in F12 or F13 frame
sizes.
3 = third drive from the left inverter module in
F14 frame size.
4 = far right inverter module in F14 frame size.
5 = rectifier module.
6 = right rectifier module in F14 frame size.
ALARM 247, Power card temperature
This alarm is only for F Frame adjustable frequency drive. It
is equivalent to Alarm 69. The report value in the alarm
log indicates which power module generated the alarm.
1 = left most inverter module.
2 = middle inverter module in F12 or F13 frame
sizes.
2 = right inverter module in F10 or F11 frame
sizes.
2 = second drive from the left inverter module in
F14 frame size.
3 = right inverter module in F12 or F13 frame
sizes.
6-8 MG34Q222 - VLT
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
®
Automation Drive FC 300 12-Pulse
3 = third drive from the left inverter module in
F14 frame size.
4 = far right inverter module in F14 frame size.
5 = rectifier module.
6 = right rectifier module in F14 frame size.
ALARM 248, Illegal power section configuration
This alarm is only for F Frame adjustable frequency drives.
It is equivalent to Alarm 79. The report value in the alarm
log indicates which power module generated the alarm:
1 = left most inverter module.
2 = middle inverter module in F12 or F13 frame
sizes.
2 = right inverter module in F10 or F11 frame
sizes.
2 = second drive from the left inverter module in
F14 frame size.
3 = right inverter module in F12 or F13 frame
sizes.
3 = third drive from the left inverter module in
F14 frame size.
4 = far right inverter module in F14 frame size.
5 = rectifier module.
6 = right rectifier module in F14 frame size.
WARNING 250, New spare part
A component in the adjustable frequency drive has been
replaced. Reset the adjustable frequency drive for normal
operation.
WARNING 251, New type code
The power card or other components have been replaced
and the type code changed. Reset to remove the warning
and resume normal operation.
