VLT Automation Drive FC 300 12-Pulse
How to Program
Instruction Manual High Power
Par. Parameter description Default value
No.
#
4-12 Motor Speed Low Limit [Hz] ExpressionLimit
4-13 Motor Speed High Limit [RPM] ExpressionLimit
4-14 Motor Speed High Limit [Hz] ExpressionLimit
4-16 Torque Limit Motor Mode ExpressionLimit
4-17 Torque Limit Generator Mode 100.0 %
4-18 Current Limit ExpressionLimit
4-19 Max Output Frequency 132.0 Hz
4-2* Limit Factors
4-20 Torque Limit Factor Source [0] No function
4-21 Speed Limit Factor Source [0] No function
4-3* Motor Speed Mon.
4-30 Motor Feedback Loss Function [2] Trip
4-31 Motor Feedback Speed Error 300 RPM
4-32 Motor Feedback Loss Timeout 0.05 s
4-34 Tracking Error Function null
4-35 Tracking Error 10 RPM
4-36 Tracking Error Timeout 1.00 s
4-37 Tracking Error Ramping 100 RPM
4-38 Tracking Error Ramping Timeout 1.00 s
4-39 Tracking Error After Ramping Timeout 5.00 s
4-5* Adj. Warnings
4-50 Warning Current Low 0.00 A
4-51 Warning Current High ImaxVLT (P1637)
4-52 Warning Speed Low 0 RPM
outputSpeedHighLimit
4-53 Warning Speed High (P413)
4-54 Warning Reference Low -999999.999 N/A
4-55 Warning Reference High 999999.999 N/A
-999999.999 Reference-
4-56 Warning Feedback Low FeedbackUnit
999999.999 Reference-
4-57 Warning Feedback High FeedbackUnit
4-58 Missing Motor Phase Function null
4-6* Speed Bypass
4-60 Bypass Speed From [RPM] ExpressionLimit
4-61 Bypass Speed From [Hz] ExpressionLimit
4-62 Bypass Speed to [RPM] ExpressionLimit
4-63 Bypass Speed To [Hz] ExpressionLimit
Table 4.9
4.3.7 5-** Digital In/Out
Par. Parameter description Default value
No.
#
5-0* Digital I/O mode
5-00 Digital I/O Mode [0] PNP
5-01 Terminal 27 Mode [0] Input
MG34Q222 - VLT ® is a registered Danfoss trademark
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
4 set-up FC 302 Change Conver- Type
only during sion
operation index
All set-ups TRUE -1 Uint16
All set-ups TRUE 67 Uint16
All set-ups TRUE -1 Uint16
All set-ups TRUE -1 Uint16
4
All set-ups TRUE -1 Uint16
All set-ups TRUE -1 Uint32
All set-ups FALSE -1 Uint16
All set-ups TRUE - Uint8
All set-ups TRUE - Uint8
All set-ups TRUE - Uint8
All set-ups TRUE 67 Uint16
All set-ups TRUE -2 Uint16
All set-ups TRUE - Uint8
All set-ups TRUE 67 Uint16
All set-ups TRUE -2 Uint16
All set-ups TRUE 67 Uint16
All set-ups TRUE -2 Uint16
All set-ups TRUE -2 Uint16
All set-ups TRUE -2 Uint32
All set-ups TRUE -2 Uint32
All set-ups TRUE 67 Uint16
All set-ups TRUE 67 Uint16
All set-ups TRUE -3 Int32
All set-ups TRUE -3 Int32
All set-ups TRUE -3 Int32
All set-ups TRUE -3 Int32
All set-ups TRUE - Uint8
All set-ups TRUE 67 Uint16
All set-ups TRUE -1 Uint16
All set-ups TRUE 67 Uint16
All set-ups TRUE -1 Uint16
4 set-up FC 302 Change Conver- Type
only during sion
operation index
All set-ups FALSE - Uint8
All set-ups TRUE - Uint8
4-13
4
