VLT Automation Drive FC 300 12-Pulse
How to Program
Instruction Manual High Power
Par. Parameter description Default value
No.
#
12-27 Master Address 0 N/A
12-28 Store Data Values [0] Off
12-29 Store Always [0] Off
12-3* EtherNet/IP
12-30 Warning Parameter 0 N/A
12-31 Net Reference [0] Off
12-32 Net Control [0] Off
12-33 CIP Revision ExpressionLimit
12-34 CIP Product Code ExpressionLimit
12-35 EDS Parameter 0 N/A
12-37 COS Inhibit Timer 0 N/A
12-38 COS Filter 0 N/A
12-4* Modbus TCP
12-40 Status Parameter 0 N/A
12-41 Slave Message Count 0 N/A
12-42 Slave Exception Message Count 0 N/A
12-5* EtherCAT
12-50 Configured Station Alias 0 N/A
12-51 Configured Station Address 0 N/A
12-59 EtherCAT Status 0 N/A
12-8* Oth. Eth. services
12-80 FTP Server [0] Disabled
12-81 HTTP Server [0] Disabled
12-82 SMTP Service [0] Disabled
12-89 Transparent Socket Channel Port ExpressionLimit
12-9* Adv. Eth. services
12-90 Cable Diagnostic [0] Disabled
12-91 MDI-X [1] Enabled
12-92 IGMP Snooping [1] Enabled
12-93 Cable Error Length 0 N/A
12-94 Broadcast Storm Protection -1 %
12-95 Broadcast Storm Filter [0] Broadcast only
12-96 Port Config null
12-98 Interface Counters 4000 N/A
12-99 Media Counters 0 N/A
Table 4.16
4.3.14 13-** Smart Logic
Par. Parameter description Default value
No.
#
13-0* SLC Settings
13-00 SL Controller Mode null
13-01 Start Event null
13-02 Stop Event null
13-03 Reset SLC [0] Do not reset SLC
13-1* Comparators
MG34Q222 - VLT ® is a registered Danfoss trademark
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
4 set-up FC 302 Change Conver- Type
only during sion index
operation
2 set-ups FALSE 0 OctStr[4]
All set-ups TRUE - Uint8
1 set-up TRUE - Uint8
All set-ups TRUE 0 Uint16
2 set-ups TRUE - Uint8
2 set-ups TRUE - Uint8
All set-ups TRUE 0 Uint16
1 set-up TRUE 0 Uint16
All set-ups TRUE 0 Uint32
All set-ups TRUE 0 Uint16
All set-ups TRUE 0 Uint16
All set-ups TRUE 0 Uint16
All set-ups TRUE 0 Uint32
All set-ups TRUE 0 Uint32
1 set-up FALSE 0 Uint16
All set-ups TRUE 0 Uint16
All set-ups TRUE 0 Uint32
2 set-ups TRUE - Uint8
2 set-ups TRUE - Uint8
2 set-ups TRUE - Uint8
2 set-ups TRUE 0 Uint16
2 set-ups TRUE - Uint8
2 set-ups TRUE - Uint8
2 set-ups TRUE - Uint8
1 set-up TRUE 0 Uint16
2 set-ups TRUE 0 Int8
2 set-ups TRUE - Uint8
2 set-ups TRUE - Uint8
All set-ups TRUE 0 Uint32
All set-ups TRUE 0 Uint32
4 set-up FC 302 Change Conver- Type
only during sion
operation index
2 set-ups TRUE - Uint8
2 set-ups TRUE - Uint8
2 set-ups TRUE - Uint8
All set-ups TRUE - Uint8
4-21
4 4
