VLT Automation Drive FC 300 12-Pulse
How to Install
Instruction Manual High Power
3.3.13 Fuses
Branch circuit protection:
In order to protect the installation against electrical and
fire hazard, all branch circuits in an installation, switch
gear, machines, etc., must be short-circuited and
overcurrent protected according to national/international
regulations.
Short-circuit protection:
The adjustable frequency drive must be protected against
short-circuit to avoid electrical or fire hazard. Danfoss
recommends using the fuses mentioned below to protect
service personnel and equipment in case of an internal
failure in the adjustable frequency drive. The adjustable
frequency drive provides full short-circuit protection in
case of a short-circuit on the motor output.
Overcurrent protection
Provide overload protection to avoid fire hazard due to
overheating of the cables in the installation. The adjustable
frequency drive is equipped with internal overcurrent
Power size Frame Rating
FC 302 Size Voltage (UL) Amperes
P250T5 F8/F9 700 700
P315T5 F8/F9 700 700
P355T5 F8/F9 700 700
P400T5 F8/F9 700 700
P450T5 F10/F11 700 900
P500T5 F10/F11 700 900
P560T5 F10/F11 700 900
P630T5 F10/F11 700 1,500
P710T5 F12/F13 700 1,500
P800T5 F12/F13 700 1,500
Table 3.24 Line Fuses, 380–500 V
Power size Frame Rating
FC 302 Size Voltage (UL) Amperes
P355T7 F8/F9 700 630
P400T7 F8/F9 700 630
P500T7 F8/F9 700 630
P560T7 F8/F9 700 630
P630T7 F10/F11 700 900
P710T7 F10/F11 700 900
P800T7 F10/F11 700 900
P900T7 F12/F13 700 1,500
P1M0T7 F12/F13 700 1,500
P1M2T7 F12/F13 700 1,500
P1M4T7 F14 700 1,500
Table 3.25 Line Fuses, 525–690 V
MG34Q222 - VLT ® is a registered Danfoss trademark
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
protection that can be used for upstream overload
protection (UL applications excluded). See 4-18 Current
Limit. Moreover, fuses or circuit breakers can be used to
provide the overcurrent protection in the installation.
Overcurrent protection must always be carried out
according to national regulations.
UL compliance
The fuses below are suitable for use on a circuit capable of
delivering 100,000 Arms (symmetrical), 240 V, or 480 V, or
500 V, or 600 V depending on the adjustable frequency
drive voltage rating. With the proper fusing, the adjustable
frequency drive Short-Circuit Current Rating (SCCR) is
100,000 Arms.
Spare
Bussmann Est. Fuse Power Loss [W]
Bussmann
P/N P/N 400 V 460 V
170M4017 176F8591 25 19
170M4017 176F8591 30 22
170M4017 176F8591 38 29
170M4017 176F8591 3,500 2,800
170M6013 176F8592 3,940 4,925
170M6013 176F8592 2,625 2,100
170M6013 176F8592 3,940 4,925
170M6018 176F8592 45 34
170M6018 176F9181 60 45
170M6018 176F9181 83 63
Spare
Bussmann Est. Fuse Power Loss [W]
Bussmann
P/N P/N 600 V 690 V
170M4016 176F8335 13 10
170M4016 176F8335 17 13
170M4016 176F8335 22 16
170M4016 176F8335 24 18
170M6013 176F8592 26 20
170M6013 176F8592 35 27
170M6013 176F8592 44 33
170M6018 176F9181 26 20
170M6018 176F9181 37 28
170M6018 176F9181 47 36
170M6018 176F9181 47 36
