VLT
How to Program
Instruction Manual High Power
Par. Parameter description
No.
#
34-30 PCD 10 Read from MCO
34-4* Inputs & Outputs
34-40 Digital Inputs
34-41 Digital Outputs
4 4
34-5* Process Data
34-50 Actual Position
34-51 Commanded Position
34-52 Actual Master Position
34-53 Slave Index Position
34-54 Master Index Position
34-55 Curve Position
34-56 Track Error
34-57 Synchronizing Error
34-58 Actual Velocity
34-59 Actual Master Velocity
34-60 Synchronizing Status
34-61 Axis Status
34-62 Program Status
34-64 MCO 302 Status
34-65 MCO 302 Control
34-7* Diagnosis readouts
34-70 MCO Alarm Word 1
34-71 MCO Alarm Word 2
Table 4.26
4.3.24 35-** Sensor Input Option
Par. Parameter description
No.
#
35-0* Temp. Input Mode
35-00 Term. X48/4 Temp. Unit
35-01 Term. X48/4 Input Type
35-02 Term. X48/7 Temp. Unit
35-03 Term. X48/7 Input Type
35-04 Term. X48/10 Temp. Unit
35-05 Term. X48/10 Input Type
35-06 Temperature Sensor Alarm Function
35-1* Temp. Input X48/4
35-14 Term. X48/4 Filter Time Constant
35-15 Term. X48/4 Temp. Monitor
35-16 Term. X48/4 Low Temp. Limit
35-17 Term. X48/4 High Temp. Limit
35-2* Temp. Input X48/7
35-24 Term. X48/7 Filter Time Constant
35-25 Term. X48/7 Temp. Monitor
35-26 Term. X48/7 Low Temp. Limit
4-32 MG34Q222 - VLT
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
®
Automation Drive FC 300 12-Pulse
Default value 4 set-up FC 302 Change
only during
operation
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups FALSE
0 N/A All set-ups FALSE
Default value 4 set-up FC 302 Change
only during
operation
[60] °C All set-ups TRUE
[0] Not Connected All set-ups TRUE
[60] °C All set-ups TRUE
[0] Not Connected All set-ups TRUE
[60] °C All set-ups TRUE
[0] Not Connected All set-ups TRUE
[5] Stop and trip All set-ups TRUE
0.001 s All set-ups TRUE
[0] Disabled All set-ups TRUE
ExpressionLimit All set-ups TRUE
ExpressionLimit All set-ups TRUE
0.001 s All set-ups TRUE
[0] Disabled All set-ups TRUE
ExpressionLimit All set-ups TRUE
® is a registered Danfoss trademark
Conver- Type
sion
index
0 Uint16
0 Uint16
0 Uint16
0 Int32
0 Int32
0 Int32
0 Int32
0 Int32
0 Int32
0 Int32
0 Int32
0 Int32
0 Int32
0 Int32
0 Int32
0 Int32
0 Uint16
0 Uint16
0 Uint32
0 Uint32
Conver- Type
sion
index
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
-3 Uint16
- Uint8
0 Int16
0 Int16
-3 Uint16
- Uint8
0 Int16
