Danfoss vlt fc 300 Instruction Manual page 83

VLT
How to Program
Instruction Manual High Power
Par. Parameter description
No.
#
16-69 Pulse Output #27 [Hz]
16-70 Pulse Output #29 [Hz]
16-71 Relay Output [bin]
16-72 Counter A
4 4
16-73 Counter B
16-74 Prec. Stop Counter
16-75 Analog In X30/11
16-76 Analog In X30/12
16-77 Analog Out X30/8 [mA]
16-78 Analog Out X45/1 [mA]
16-79 Analog Out X45/3 [mA]
16-8* Fieldbus & FC Port
16-80 Fieldbus CTW 1
16-82 Fieldbus REF 1
16-84 Comm. Option Status
16-85 FC Port CTW 1
16-86 FC Port REF 1
16-9* Diagnosis Readouts
16-90 Alarm Word
16-91 Alarm word 2
16-92 Warning Word
16-93 Warning word 2
16-94 Ext. Status Word
Table 4.20
4.3.18 17-** Motor Feedb.Option
Par. Parameter description
No.
#
17-1* Inc. Enc. Interface
17-10 Signal Type
17-11 Resolution (PPR)
17-2* Abs. Enc. Interface
17-20 Protocol Selection
17-21 Resolution (Positions/Rev)
17-24 SSI Data Length
17-25 Clock Rate
17-26 SSI Data Format
17-34 HIPERFACE Baud rate
17-5* Resolver Interface
17-50 Poles
17-51 Input Voltage
17-52 Input Frequency
17-53 Transformation Ratio
17-56 Encoder Sim. Resolution
17-59 Resolver Interface
4-26 MG34Q222 - VLT
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20872-Danfoss-131H4490-VLT-Automation-VT-Drive-VFD-FC302-460V-25-HP.aspx
®
Automation Drive FC 300 12-Pulse
Default value 4 set-up FC 302 Change
only during
operation
0 N/A All set-ups FALSE
0 N/A All set-ups x FALSE
0 N/A All set-ups FALSE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0 N/A All set-ups TRUE
0.000 N/A All set-ups FALSE
0.000 N/A All set-ups FALSE
0.000 N/A All set-ups FALSE
0.000 N/A All set-ups FALSE
0.000 N/A All set-ups FALSE
0 N/A All set-ups FALSE
0 N/A All set-ups FALSE
0 N/A All set-ups FALSE
0 N/A All set-ups FALSE
0 N/A All set-ups FALSE
0 N/A All set-ups FALSE
0 N/A All set-ups FALSE
0 N/A All set-ups FALSE
0 N/A All set-ups FALSE
0 N/A All set-ups FALSE
Default value 4 set-up FC 302 Change
only during
operation
[1] TTL (5V, RS4222) All set-ups FALSE
1024 N/A All set-ups FALSE
[0] None All set-ups FALSE
ExpressionLimit All set-ups FALSE
13 N/A All set-ups FALSE
ExpressionLimit All set-ups FALSE
[0] Gray code All set-ups FALSE
[4] 9600 All set-ups FALSE
2 N/A 1 set-up FALSE
7.0 V 1 set-up FALSE
10.0 kHz 1 set-up FALSE
0.5 N/A 1 set-up FALSE
[0] Disabled 1 set-up FALSE
[0] Disabled All set-ups FALSE
® is a registered Danfoss trademark
Conver- Type
sion
index
0 Int32
0 Int32
0 Int16
0 Int32
0 Int32
0 Uint32
-3 Int32
-3 Int32
-3 Int16
-3 Int16
-3 Int16
0 V2
0 N2
0 V2
0 V2
0 N2
0 Uint32
0 Uint32
0 Uint32
0 Uint32
0 Uint32
Conver- Type
sion
index
- Uint8
0 Uint16
- Uint8
0 Uint32
0 Uint8
3 Uint16
- Uint8
- Uint8
0 Uint8
-1 Uint8
2 Uint8
-1 Uint8
- Uint8
- Uint8
