Instruction Manual High Power

1 How to Read the Instruction Manual

The adjustable frequency drive is designed to provide high
shaft performance on electrical motors. Please read this
manual carefully for proper use. Incorrect handling of the
adjustable frequency drive may cause improper operation
of the adjustable frequency drive or related equipment,
shorten lifetime or cause other problems.
This Instruction Manual will help you get started as well as
install, program, and troubleshoot your adjustable
frequency drive.
Chapter 1, How to Read this Instruction Manual, introduces
the manual and informs you of the approvals, symbols and
abbreviations used in this literature.
Chapter 2, Safety Instructions and General Warnings,
contains instructions on how to handle the adjustable
frequency drive correctly.
Chapter 3, How to Install, guides you through mechanical
and technical installation.
Chapter 4, How to Program, shows how to operate and
program the adjustable frequency drive via the LCP.
Chapter 5, General Specifications, contains technical data
about the adjustable frequency drive.
Chapter 6, Warnings and Alarms, assists you in solving
problems that may occur when using the adjustable
frequency drive.
Available literature
- The VLT AutomationDrive Instruction Manual - High
Power, MG33UXYY provides the necessary
information for getting the adjustable frequency
drive up and running.
- The VLT AutomationDrive Design Guide MG33BXYY
provides all the technical information about the
adjustable frequency drive and customer design
and applications.
- The VLT AutomationDrive Programming Guide
MG33MXYY provides information on how to
program and includes complete parameter
descriptions.
- The VLT AutomationDrive Profibus Instruction
Manual MG33CXYY provides the information
required for controlling, monitoring and
