Figure 3.3 Recommended lifting method, frame size
F11/F12/F13/F14.
NOTE!
The plinth is provided in the same packaging as the
adjustable frequency drive but is not attached during
shipment. The plinth is required to allow airflow to the
adjustable frequency drive to provide proper cooling. The
F frames should be positioned on top of the plinth in the
final installation location. The angle from the top of the
adjustable frequency drive to the lifting cable should be
60° or greater.
In addition to the drawings above, a spreader bar is an
acceptable way to lift the F Frame.
