VLT Automation Drive FC 300 12-Pulse
How to Program
Instruction Manual High Power
Par. Parameter description Default value
No.
#
14-40 VT Level 66 %
14-41 AEO Minimum Magnetization
14-42 Minimum AEO Frequency 10 Hz
14-43 Motor Cos-Phi
14-5* Environment
14-50 RFI Filter [1] On
14-52 Fan Control [0] Auto
14-53 Fan Monitor [1] Warning
14-55 Output Filter [0] No Filter
14-56 Capacitance Output Filter 2.0 uF
14-57 Inductance Output Filter 7.000 mH
14-59 Actual Number of Inverter Units
14-7* Compatibility
14-72 VLT Alarm Word 0 N/A
14-73 VLT Warning Word 0 N/A
14-74 VLT Ext. Status Word 0 N/A
14-8* Options
14-80 Option Supplied by External 24 V DC [1] Yes
Table 4.18
4.3.16 15-** Drive Information
Par. Parameter description Default value
No.
#
15-0* Operating Data
15-00 Operating Hours 0 h
15-01 Running Hours 0 h
15-02 kWh Counter 0 kWh
15-03 Power-ups 0 N/A
15-04 Over Temps 0 N/A
15-05 Over Volts 0 N/A
15-06 Reset kWh Counter [0] Do not reset
15-07 Reset Running Hours Counter [0] Do not reset
15-1* Data Log Settings
15-10 Logging Source 0
15-11 Logging Interval ExpressionLimit
15-12 Trigger Event [0] FALSE
15-13 Logging Mode [0] Log always
15-14 Samples Before Trigger 50 N/A
15-2* Historic Log
15-20 Historic Log: Event 0 N/A
15-21 Historic Log: Value 0 N/A
15-22 Historic Log: Time 0 ms
15-3* Fault Log
15-30 Fault Log: Error Code 0 N/A
15-31 Fault Log: Value 0 N/A
15-32 Fault Log: Time 0 s
