Network Clouds

Network Clouds

Add MPLS Cloud Dialog Box

Polycom, Inc.
In Step 2 of the wizard, select the second site for the exclusion. Click Next.
4
In Step 3 of the wizard, review the exclusion and click Done if it's correct.
5
The Network Clouds page contains a list of the MPLS (Multiprotocol Label
Switching) network clouds defined in the site topology.
If the system is integrated with a CMA system, it receives MPLS network
information from that system, and this page is read-only. If not, you can enter
MPLS network cloud information.
The commands in the Actions list let you add an MPLS cloud and edit or
delete existing MPLS clouds.
The following table describes the fields in the list.
Table 8-11 Information in the Network Clouds list
Column/Section
Name
Description
Lets you define a new MPLS network cloud in the Polycom DMA system's site
topology. The following table describes the fields in the dialog box.
Table 8-12 Add MPLS Cloud dialog box
Field
Cloud Info
Name
Description
Linked Sites
Search Sites
Search Result
Linked Sites
Description
Name of the cloud.
Description of the cloud.
Description
A meaningful name for the cloud (up to 128 characters).
A brief description of the cloud (up to 200 characters).
Enter search string or leave blank to find all sites.
Lists sites found.
Select a site and click the right arrow to open the Add
Site Link dialog box (see
page 123).
Lists sites linked to the cloud.
Site Topology Configuration
"Add Site Link Dialog Box" on
125
