Site Topology Configuration Procedures
Polycom, Inc.
Click OK.
c
Go to Configuration > Site Topology > Network Clouds, and for each
4
MPLS network cloud in your network topology, do the following:
In the Actions list, click Add.
a
The Add MPLS Cloud dialog box appears.
In the Cloud Info section, enter a name and description for the cloud.
b
In the Linked Sites section, display the sites you defined. See
c
MPLS Cloud Dialog Box"
Select the first site linked to this cloud and click the arrow button to
d
move it to the Linked Sites list.
The Add Site Link dialog box appears.
Define the link. See
e
Repeat the previous two steps for each additional site linked to this
f
cloud.
Click OK.
g
Go to Configuration > Site Topology > Site-to-Site Exclusions, and for
5
each exclusion in your network topology, do the following:
In the Actions list, click Add.
a
Complete the Add Site-to-Site Exclusions wizard. See
b
Site-to-Site Exclusion Wizard"
Your site topology information is complete. For conferences with cascading
enabled, the Polycom DMA system can use it to route calls to the nearest
eligible MCU (based on pools and pool orders) that has available capacity and
to create the cascade links between MCUs.
Note
If in the future, you integrate this system with a Polycom CMA 5000 system, the site
topology information from the Polycom CMA system will replace the information you
entered.
on page 125.
"Add Site Link Dialog Box"
on page 124.
Site Topology Configuration
"Add
on page 123.
"Add
