8.4.11.1

Serial Port 1 Configuration Submenu

Feature
Serial Port
Device Settings
Change Settings
8.4.11.2

Serial Port 2 Configuration Submenu

Feature
Serial Port
Change Settings
Device Mode
8.4.12

Serial Port Console Redirection Submenu

Feature
COM0 Console Redirection
►Console Redirection Settings
COM1 Console Redirection
Copyright © 2016 congatec AG
Options
Disabled
Enabled
No option
Auto
IO=3F8; IRQ=4;
IO=3F8; IRQ=3,4,5,6,7,9,10,11, 12;
IO=2F8; IRQ=3,4,5,6,7,9,10,11, 12;
IO=3E8; IRQ=3,4,5,6,7,9,10,11, 12;
IO=2E8; IRQ=3,4,5,6,7,9,10,11, 12;
Options
Enabled
Disabled
Use Automatic Settings
IO=2F8; IRQ=3;
IO=3F8; IRQ=3,4,5,6,7,9,10,11, 12;
IO=2F8; IRQ=3,4,5,6,7,9,10,11, 12;
IO=3E8; IRQ=3,4,5,6,7,9,10,11, 12;
IO=2E8; IRQ=3,4,5,6,7,9,10,11, 12;
Standard Serial Port Mode
IrDA Active pulse 1.6 uS
IrDA Active pulse 3/16 bit time
ASKIR Mode
Options Description
Disabled Enable or disable serial port 0 console redirection.
Enabled
Submenu Opens 'Console Redirection Settings' submenu.
Disabled Enable or disable serial port 0 console redirection.
Enabled
Description
Enable or disable serial port (COM).
Displays current device settings.
Serial Port 1 configuration options.
Description
Enable or disable serial port (COM).
Serial Port 2 configuration options.
Select the serial port mode.
