Super I/O Submenu

Feature
SIO Clock
PS/2 Keyboard/Mouse Support
Serial Port 0
Device Settings
Serial Port 1
Device Settings
Parallel Port
Device Settings
Device Mode
Note
This setup menu is only available if an external Winbond W83627 Super I/O has been implemented on the carrier board.
11.4.16

Serial Port Console Redirection Submenu

Feature
COM0
Console Redirection
►Console Redirection Settings submenu
COM1
Console Redirection
►Console Redirection Settings submenu
Note
The Serial Port Console Redirection can be enabled (functional) only if an external Super I/O offering UARTs has been implemented on the
carrier board
Copyright © 2013 congatec AG
Options Description
24MHz Select Super I/O base clock
48MHz
Disabled Enable or disable PS/2 keyboard/mouse controller support.
Enabled
Disabled Enable or disable serial port 0.
Enabled
IO=3F8h; IRQ=4; Fixed configuration of serial port 0 if enabled.
Disabled Enable or disable serial port 1.
Enabled
IO=2F8h; IRQ=3; Fixed configuration of serial port 1 if enabled.
Disabled Enable or disable parallel port.
Enabled
IO=378h; IRQ=7; Fixed configuration of the parallel port if enabled.
Standard Parallel Mode Set the parallel port mode.
EPP Mode
ECP Mode
EPP Mode & ECP Mode
Options Description
Disabled Enable or disable serial port 0 console redirection.
Enabled
Opens console redirection configuration sub menu.
Disabled Enable or disable serial port 1 console redirection.
Enabled
Opens console redirection configuration sub menu.
