10
BIOS Setup Description
The BIOS setup description of the conga-MA5 can be viewed without having access to the module. However, access to the restricted area of
the congatec website is required in order to download the necessary tool (CgMlfViewer) and Menu Layout File (MLF).
The MLF contains the BIOS setup description of a particular BIOS revision. The MLF can be viewed with the CgMlfViewer tool. This tool offers
a search function to quickly check for supported BIOS features. It also shows where each feature can be found in the BIOS setup menu.
For more information, read the application note "AN42 - BIOS Setup Description" available at www.congatec.com.
Note
If you do not have access to the restricted area of the congatec website, contact your local congatec sales representative.
10.1
Navigating the BIOS Setup Menu
The BIOS setup menu shows the features and options supported in the congatec BIOS. To access and navigate the BIOS setup menu, press
the <DEL> or <F2> key during POST.
The right frame displays the key legend. Above the key legend is an area reserved for text messages. These text messages explain the options
and the possible impacts when changing the selected option in the left frame.
10.2
BIOS Versions
The BIOS displays the BIOS project name and the revision code during POST, and on the main setup screen. The initial production BIOS for
conga-MA5 is identified as MA50R1xx, where:
• MA5 is the project name
• R is the identifier for a BIOS ROM file
• 1 is the feature number
• xx is the major and minor revision number.
The binary size of conga-MA5 BIOS is 8 MB.
Copyright © 2017 congatec AG
MA50m17
58/60
