BIOS Setup Description

8.1

Navigating the BIOS Setup Menu

The BIOS setup menu shows the features and options supported in the congatec BIOS. To access and navigate the BIOS setup menu, press
the <DEL> or <F2> key during POST.
The right frame displays the key legend. Above the key legend is an area reserved for text messages. These text messages explain the options
and the possible impacts when changing the selected option in the left frame.
8.2

BIOS Versions

The BIOS displays the BIOS project name and the revision code during POST, and on the main setup screen. The initial production BIOS for
conga-IA5 is identified as IA50R1xx, where:
• IA5 is the project name
• R is the identifier for a BIOS ROM file
• 1 is the feature number
• xx is the major and minor revision number.
The binary size of conga-IA5 BIOS is 8MB.
8.3

Updating the BIOS

OEMs often use BIOS updates to correct platform issues discovered after the board has been shipped or when new features are added to the
BIOS. The conga-IA5 uses a congatec/AMI AptioEFI firmware, which is stored in an onboard flash ROM chip and can be updated using the
congatec System Utility. The utility has four versions—DOS based command line, Win32 command line, Win32 GUI, and Linux version.
For more information about "Updating the BIOS" refer to the user's guide for the congatec System Utility "CGUTLm1x.pdf" on the congatec
website at www.congatec.com.
8.4

Supported Flash Device

The conga-IA5 supports Winbond W25Q64FW (8MB) flash device.
