7.2.8

Bus Master Inserts

Each Group, Mix, and Aux Bus has an insert point. See Mix Bus Send/Return on page
49 to learn about bus insert send and returns specified in PatchNet. Switching the insert
in/out works the same for Aux, Mix, and Group busses.
1. Press the Aux Mstrs, Grp Mstrs, or Mix Mstrs button to display that bus on
the Bus Master knobset.
2. Press both cfg
3. Press the lower button to the left of the knob to activate that bus insert (In: but-
ton lit). Press the button again to deactivate the bus insert (Out: button not lit).
7.3

Mix and Group Bus Setup

See Busses on page 51 to learn about how to configure the Mix and Group Busses.
7.4

Bus Processing

Digital processing can be performed on up to 16 Mix, Group, or Aux busses. The
number of busses available for processing is determined by the Mixer Model. The
processing functions include a limiter, compressor, and filters. The selected busses
(Figure 7-4) can be assigned to a channel strip (see page 97) to allow for parameter
adjustments.
and keys simultaneously.
Figure 7-4 Bus Processing Configuration
94
Busses and Bus Masters
