System 5 Digital Audio Mixing System Operation Manual

14.13 Managing the Automation

14.13.1 Group Coalesce

Group Coalesce transfers automation from the Control Group master fader to the
slaves.
1. Press the Panel Viewer's Main Panel key.
2. Press the Groups button to display the Groups Panel.
3. Press the Coalesce key at the bottom of the Groups Panel.
The Coalesce key begins flashing.
4. Press the Groups key for the group to coalesce.
All master fader moves get transferred to the slaves and the Control Group is deleted.

14.13.2 Mix Passes

A mix pass is created each time an automation punch in occurs until the tape stops. If
the tape stops before the last parameter punches out, the pass consists of all automation
from the first parameter punched in to when playback stops. If playback stops after a
punch out, the pass ends when the last parameter punches out.
Each pass is stored automatically and numbered chronologically. All mix passes are
saved with a Mix and loaded when the Mix is re-opened (see Save Mix below).
View Mix Passes
Press the Pass View key at the top of the center section Automation Panel to display
the Pass Tree. To navigate through the Pass Tree to activate a different pass:
1. Rotate the SpinKnob clockwise to move to higher pass numbers, counter-
clockwise to move to lower numbers.
2. Press the Enter key to select the highlighted pass.
0 1 2 3
4
Figure 14-14 Mix Pass tree
207
5 6 7
8 9
Dynamic Automation
10
