Chapter 15: CM403 Film/Post Module
15.1 CM403 [S5P only]
The CM403 fulfills the requirements for a traditional PEC/Direct monitoring system for
the post-production environment. It can be used in single- and multi-operator System 5
consoles. Up to four Post Panels can be installed in a single system. The form factor of
the CM403 is the same as the other CM40x standard control modules. The CM403
houses a TFT and has three same-size panels (i.e., the Film Panel and the Dual-Joystick
Panel). The film panel can be placed above or below the joysticks depending on the
preference of the operator. The user has the option of placing their own motion controller
or other third-party equipment into the spare panel.
Figure 15-1 CM403 Film/Post Module
