System 5 Digital Audio Mixing System Operation Manual
Aux Busses
Press the Aux key at bottom right of the Comms:Talkback Panel to display the Aux
busses. The same rules apply to the Aux Busses as monitors. Select the Aux Busses
(single or pairs) to route the talkback signals. They latch or are momentary based on the
Tbk Ltch setting and their levels are set on the Mons page.
NOTE: The talkback signal must be patched in order to be routed to the Aux Bus-
ses. See 4.2.8 Talkback Signal Patching on page 50.
5.2.2

Listenback

Press the Lsn key at the bottom of the Comms:Talkback Panel to display the
Comms:Listenback Panel (Figure 5-6).
Listen mic
speaker
assignment
Listen mic
follows active
CR speaker
Listen mics
On/Off
All Listen mics
on when active
Comms: Listenback
DimCR
Lsn>MonA
Lsn>Alt1
Lsn>MonB
Lsn>Alt2
Lsn>MonC
Lsn>Flw Lsn>MonD
Lsn1 -14.2
4>Lsn
Lsn2 -14.2
3>Lsn
Lsn3 -9.00
2>Lsn
1>Lsn Lsn4 -9.31
Lsn Ltch
All>Lsn
Main
Panel
Talk Lsn OscSlt
Figure 5-6 Comms:Listenback Panel
70
CM401T Master Section
Dims CR
when Listen
mic is on
Listen mic
monitor
assignments
Listen mic
level control
Listen mics
latch when active;
momentary when
inactive
