System 5 Digital Audio Mixing System Operation Manual
Changing the Mixer Model
1. Click the System tab at the bottom of the eMix Window.
2. From the list on the left of the System window, select the desired Mixer Model.
The name of the Mixer Model describes the sample rate, number of channels,
and bus architecture. The central part of the window displays the hardware con-
figuration required to run the Mixer Model selected.
3. If your system has the required hardware and this is the proper configuration,
click Activate This Mixer Model
4. eMix will prompt you to restart the system. Click OK to restart eMix.
If the new mixer model has a different sample rate, see below. If not, power off the con-
trol surface, and digital core(s) and reboot.
Figure 4-19 Mixer Models
.
54
eMix Application
