System 5 Digital Audio Mixing System Operation Manual

Speaker Re-Assign

The system automatically sends mix busses to the correct monitor bus based on the bus
format. For example, when monitoring fx1, the left bus of the section is automatically
sent to the left monitor bus. It is sometimes necessary to override this assignment and
send a mix bus to a different monitor bus than was intended.
Alt 1
Main
L
Spkrs Spkrs
Alt 2
Monitor
Insert Spkrs C
R
Dim Cut
S l
Rec's
S r
Ext's
B
Spkr
Lock
Asgn
Solo Fold
Ctrl Down
Figure 15-6 Speaker Re-assign
219
CM403 Film/Post Module
Talk
