Normalled Connections
The inputs and outputs that require normalled connections should be designated in
PatchNet and saved to the Title Defaults.
In this example, the console group bus outputs 1–24 should be patched to the DAW
inputs. Figure 4-7 shows the Nuendo inputs patched from the Group Bus outputs.
If a Source is normalled to multiple destinations, <MULT> appears in the cell next to
the source.
Figure 4-7 Destinations normalled
40
eMix Application
