System 5 Digital Audio Mixing System Operation Manual
Faders
Named
Group Bus
Presets
Mix Bus
Un-named
M4
Presets
M5
M6
M7
M8
M9
M10
M11
M12
◄
Pg01
Main
Panel
Sto Clr
Store current
Delete
a Preset
meter settings
to a Preset
Figure 5-11 Meter Presets and Meter Configuration Panels
Meter Configuration
Press the Cnfg key at the bottom of the Meter Presets Panel. The Meter Configuration
Panel appears (right of Figure 5-11). By default, the Full key (bottom-left) is lit, which
selects one large meter; the Channel key is also lit, which displays the Channel options
along the right side of the Panel. The double arrows (depicted opposite Channel in
Figure 5-11) show what the right-side options pertain to (i.e., press Group to display
Grp 1, Grp 2, etc. along the right side and the arrows appear opposite Group).
Each Strip can have a different meter configuration but it is also easy to assign the same
configuration to consecutive Strips (with automatic incrementing).
Meter Presets
M13
M14
M15
M16
M17
M18
M19
M20
M21
M22
M23
M24
►
Info
Name Peak Avg Cnfg
Name Toggle, Peak, or Configure
a Preset meters
Average for all
meters
Meter Configuration
Channels < >
Masters
Busses:
Group
Mix
Aux
None
Main
Panel
Full Dual Upr
Single, large Two, small Select
meter meters upper dual
meter
78
CM401T Master Section
Fader
Main
Swap
1 : C1
2 : C2
3 : C3
4 : C4
5 : C5
6 : C6
7 : C7
8 : C8
9 : C9
◄ ►
Pg01
Info
Lwr Pset
Select Back to Meter
lower dual Presets Panel
meter
