System 5 Digital Audio Mixing System Operation Manual
12.1

Transport Controls

The Transport section has the standard Play, Rewind, Fast Forward, Stop, and
Record keys. The following keys provide additional transport functions:
Press the Shuttle key (it lights) to allow the SpinKnob to move the transport
Shuttle
Press the Jog key (it lights) to allow the SpinKnob to move the transport
Jog
Shuttle
L o c Trim
Roll
Back
Figure 12-2 Transport Controls
backwards or forwards. The speed depends on the degree of the SpinKnob's
rotation. Press the Shuttle key again to deactivate.
backwards or forwards. The speed depends on the degree of the SpinKnob's
rotation; maximum rotation moves the transport at the Play speed. This
function is helpful for setting precise edit and cue points. Press the Jog key
again to deactivate.
Jog Return
Punch
154
Machine Control
Reh
Auto
Rec
