System 5 Digital Audio Mixing System Operation Manual

Chapter 13: GPI/O Event System

The event system can program many System 5 features. The following features are very
useful:
•
use a fader to start a cart machine or turn speakers on/off;
•
turn a channel on/off in response to a camera turning on/off.
An event consists of a set of input conditions governed by a logical operator that deter-
mines the output condition. Inputs can be surface parameters (i.e., channel on, fader,
etc.) or external inputs via the TT002. Outputs can be System 5 parameters or external
outputs via the TT002.
TT002
Besides being a machine controller, the TT002 is used to communicate to devices
that use tallies and relays. It replaces the GP132 General Purpose Input/Output Relay
System and the TT007 Machine Control Hub. An optional machine control extender
unit can be ordered for systems requiring control of multiple machines.
Although the TT002 is shipped with all systems, many events do not require it.
163
