System 5 Digital Audio Mixing System Operation Manual
13.9.4

Move a Fader to Stop a Cart Machine

This example demonstrates how to stop a Cart machine by moving a fader below a se-
lected level.
1. In the Event Configuration window, under Event List, click on the <click to
add event> field.
The Add Event dialog appears.
2. Select AND as the logical operator from the dropdown menu.
3. Under Input, click on the <click to add input> field.
The Add Input Event dialog appears.
4. Select Fader from the dropdown menu and click OK.
5. Configure the Input Properties to the following settings:
Channel #
Activation level (dB) -55
Activation Type
6. Under Output, click on the <click to add output> field.
The Add Output Event dialog appears.
7. Select GPO from the dropdown menu and click OK.
8. Configure the Output Properties to the following settings:
Output Number
Active State
Pulse Length
Machine
2
Below
2
Closed
10
TT002
172
GPI/O Event System
