New Title Dialog - Euphonix System 5 Manual

System 5 Digital Audio Mixing System Operation Manual
Create New Title
1. Click the Drives tab to see a list of available Drives.
2. Select the desired Drive and click the Projects tab or double-click the Drive.
The Projects Window appears with a list of Projects on that Drive.
3. Select a Project and click the Titles tab or double-click the Project.
The Titles Window appears with all Titles in that Project.
4. Click the New button along the right side of the Titles window.
The New Title dialog appears.
5. Name the new Title and select one of the Creation Options radio buttons:
•
Save the current title and mix data into the new title: Uses the current state
of the console for new Title. If a mix is open, that mix is saved in the new title.
•
Reset Console with Default Title settings: Uses settings for Default Title to
reset console. See page 39 to see how to change the default settings. There is
no mix in the new title; one must be explicitly created.
NOTE: A Title appears as a folder but is actually a single file with multiple Mixes.
Figure 4-3 New Title dialog
35
eMix Application
