Euphonix System 5 Manual page 220

System 5 Digital Audio Mixing System Operation Manual CM403 Film/Post Module
It is now possible to use the Exp/Sel keys above the displays on the PEC/DIR paddle
to select busses within a section. When a bus is selected, the Speaker Re-Assign panel
illuminates the current monitor bus assignment. Selecting a different speaker from the
panel re-assigns the bus within the monitor matrix.
Lock
Hold down the CM403's Wave key and press the Lock button. Lock lights when
active. Hold down the Wave and press Lock again to disable the function.
Solo Control
The Solo Control switch controls the solo modes, which are similar to those in the
CM401T: summing, intercancel, momentary, and safe.
Solo Safe is applied to the stems by selecting the Exp/Sel key above the stem you wish
to make safe.
220
