14. Sensor Kit

14.1 Description

Intermec EasyCoder 501 – Service Manual Ed. 7
As an option, the EasyCoder 501 E and EasyCoder 501 SA can
be fi tted with two sensors, that detect the rotation of the media
supply spool and the ribbon unwind shaft and update two coun-
ters, one for each sensor. By means of custom-made application
programs, the counters can be read and used for indicate paper-low
and ribbon-low conditions (as opposed to out-of-paper and out-of-
ribbon conditions, which are supported by the standard error han-
dling). See SYSVAR system array in Intermec Fingerprint v6.14,
Reference Manual.
The sensors require no regular cleaning. However, should any mal-
function be detected, you may try to blow the sensor clear from
dust or media residue before replacing it.
The sensitivity of these sensors cannot be adjusted.
Ribbon Low Sensor
Chapter 14
Media Low Sensor
