13.1 Description, cont.
Intermec EasyCoder 501 – Service Manual Ed. 7
Bus Driver Board; Components Diagrams
Bus Driver Board as fi tted on the CPU Board
P2
C3
D1
971712.ØØ
P1
P1 MOUNTED ON SOLDERING SIDE
Bus Driver Board 1-971712-25; Components
Chapter 13 Memory Card Adapter
107
