Chapter 2 Front and Keyboard
2.4 Slides
18
The slide can be removed through a slot at the right side of the
keyboard using a small pair of pliers. The slide can be replaced by
another one, for example to adapt the printer for a certain language
or a special application. There are three different standard slides
with English text as shown below
Power
Ready
Error
Keyboard of EasyCoder 501 S
Power
Ready
Error
F1
F 2
F 3
F4
F 5
Keyboard of EasyCoder 501 E and 501 LinerLess
Keyboard of EasyCoder 501 SA
7
Pause
4
Setup
1
Feed
,
Enter
Intermec EasyCoder 501 – Service Manual Ed. 7
Pri nt
8
9
5
6
2
3
Pri nt
0
C
˘ ˘
