Chapter 8 Print Unit
8.2 Main Parts, cont.
EasyCoder 501 S, E, and SA
Headlift Mechanism
Stepper Motor
Platen Roller
Tear Bar
Liner Drive Roller
Printhead
Intermec EasyCoder 501 – Service Manual Ed. 7
44
