2.5 Keyboard Interface Board;
Components Diagram
LED1
P2
Keyboard Interface Board 1-040701-26; Components Diagram
Intermec EasyCoder 501 – Service Manual Ed. 7
R1
LED2
R2
Connections:
P-1
Permanently attached cable to
P-2 on CPU Board
P-2
LCD Display (soldered)
P-3
Keyboard
P-4
Provision for separate print key
(for special applications)
Chapter 2 Front and Keyboard
LED3
R3
C3
C1
C4
+
P4
RN2
P1
19
