User Guide
3. Select the adapters to include in the team.
4. Select "Adapter Fault Tolerance" or "Adaptive Load Balancing" and click
[Next].
5. Check the adapter to join the team and click [Next].
6. Click [Finish].
7. The setup will go back to [Intel(R) PROSet for Wired Connections] dialog box,
so click [OK].
8. Restart the system.
Graphics Accelerator Driver
The drivers for the graphics accelerator cards that are installed in the server will setup
automatically.
If you remove an additional graphics card, make sure to remove its corresponding
driver.
Should it be necessary to install manually the drivers, follow the procedure below.
If you want to use an optional graphics acceletaror card, setup the card according to
what is written in the card's documentation.
1. Insert the NEC ExpressBuilder CD-ROM into the DVD-ROM drive.
2. Click Start menu, point to [Programs], [Accessories] and click [Windows
Explorer]
3. Run "SETUP.EXE" in the following directory.
To install a standard graphics accelerator driver:
<DVD-ROM
SETUP.EXE
To install a graphics accelerator ATI RN50 driver:
<DVD-ROM
SETUP.EXE
4. Follow the on-screen instructions to continue the installation. If a message
"Digital signature could not be found" appears, select Yes to continue.
5. Remove the NEC ExpressBuilder CD-ROM from the DVD-ROM drive,
follow the on-screen directions and restart the system.
Installing SCSI Controller Drivers
Update the drivers for your system using the NEC ExpressBuilder CD-ROM shipped
with your system.
The SCSI drivers will be installed automatically.
Installing a Disk Array Controller Driver (SecuRAID 114, SecuRAID
121)
To install these controllers on a system running under Windows Server 2003, connect
the controller and take the following steps to install the driver:
drive
Letter>:\WINNT\W2K3AMD\VIDEO\MATROX/
drive
Letter>:\WINNT\W2K3AMD\VIDEO\ES1000/
291
www.nec-computers.com
