User Guide
Removing the Front Door
Open the front door to power on/off the server, to access the floppy disk drive, optical
disc drive, and 5.25-inch devices, and to install/remove hard disks to the 3.5-inch
device bays.
To remove the front door:
1. Insert the provided security key into the key hole and turn the key to unlock the
front door (See the following figure).
2. Hold the front door edges and gently pull the door away from the server
chassis.
A
Do not open the front door by hanging the handle at the upper
left corner with your claws. If the front door cannot be opened
easily, hold the upper left and lower left corners of the front door
with your hands and then pull it out toward you.
the 5 1/4-inch devices such as an optical disc drive have a
function to eject a tray or media using a software command.
Before issuing a software command to eject a tray or media,
confirm that the front door is open. If the command is executed
while the front door is closed a tray or media may run into the
front door resulting in an error or may cause the unit to fail.
Installing the Front Door
When you close the front door, lock the door with the key for security.
1
2
B
Figure 35: Opening the Front Door
B: Unlock
Note: The standard optical disc drive and some options for
A: Lock
Caution
63
www.nec-computers.com
